Description
- 6-channel RCA Line Input &
8-channel RCA Line Output - 4-channel High Level Input
- Bluetooth Signal Input
- Digital Input: coaxial and optical input
- Support 5.1 Decoding (Dobly Decode)
- Support Wi-Fi (only for Windows PC)
- Frequency Response: 10Hz – 20KHz
- S/N Ratio: >110dB
- T.H.D: <0.02 %
- Control Method: DSP Controller and Computer
- Dimension: 36mm(H) X 150mm(W) X 230mm(L)
DSP-Software Feature:
- Crossover Frequency: 20Hz – 20KHz
- Output Gain: -60dB – 0dB• 31-Band GEQ /PEQ for all channels
- EQ Gain: -20dB – +20dB per band
- Filter Mode: Linkwitz-Riley, Butterworth and Bessel
- 0dB – 48dB/Oct Crossover HP/LP
- Phase Shift 0°/180°
- Time Delay 0-20ms/0-692cm per channel
- 6 setting storable on the device
